OPL for KiCAD

As a first step toward a fully native KiCad version of the Seeed OPL, we’ve used a script to export the current Eagle library as outlined in the recipe HERE. This machine-created alpha version is functional but has not been verified so should be used with caution. Silkscreen and symbol texts are not yet aligned The Electrical Types for pins are unset in the symbol library so ERC in Eeschema may show unexpected errors 3D …

Read more 0 Comments
