Gear (reduction ) motor p12 6V 60RPM

Gear (reduction ) motor p12 6V 60RPM

SKU 108100005
9.00
7 Available
$9.00/ 1pcs+

Description



Gear (reduction ) motor,made in Shenzheng, China, pretty good quality, running a speed at 60rpm. All you need to do is connect the postive and  negative pole-pin, simple enough for beginners.


Specifications
  • Operating Voltage: DC 2.4 ~ 6.0V

  • No Load Speed: 55 ~ 70rmp

  • No Load Current: 30 ~ 70mA

  • Max. Efficiency Speed: 40 ~ 52rpm

  • Max. Efficiency Current: 350 ~ 450mA

  • Torque: 0.7 ~ 1.2kg.cm

  • Stall Current: 500 ~ 700mA

  • Stall Torque: 3.0 ~ 4.0kg.cm



Technical Details

Dimensions0mm x 0mm x 0mm
WeightG.W 10g
BatteryExclude

Part List

Gear (reduction ) motor p12 6V 60RPM1

ECCN/HTS

ECCNERA99
HSCODE8501101000

Reviews

Questions and Answers

SUBMIT
0
Can i change reduction ratio. I need motor with RPM level at ~150-250.
on Oct 19,2016
Reply upvote ()
Sorry, we only the distributor for this product, what you need is another motor. If you really interest in it , hope you could send your requirement to our Wish page(http://www.seeedstudio.co
on Oct 20,2016 10:43 AM
Reply upvote ()
Hi, thanks for your feedback, it will be helpful if you could send your require to our Wish(http://www.seeedstudio.com/wis... .
on Oct 20,2016 10:45 AM
Reply upvote ()
