Particle Argon IoT Development Board (Wifi+Mesh+Bluetooth)

SKU
113990597
Particle Argon IoT Development Board (Wifi+Mesh+Bluetooth),mesh networking,device to device networking,self-healing networks,end to end,standalone Wi-Fi endpoint or Wi-Fi enabled gateway,Nordic nRF52840,Particle Device Cloud,ESP32,Thread,Bluetooth 5,BLE
$25.90
Out of stock
  • 50+: $24.90

The Argon is a powerful Wi-Fi enabled development board that can act as either a standalone Wi-Fi endpoint or Wi-Fi enabled gateway for Particle Mesh networks. It is based on the Nordic nRF52840 and has built-in battery charging circuitry so it’s easy to connect a Li-Po and deploy your local network in minutes.

The Argon is great for connecting existing projects to the Particle Device Cloud or as a gateway to connect an entire group of local endpoints.

All Particle Hardware is designed from the ground up to work with the Device Cloud; a powerful set of tools and infrastructure to build, connect, and manage your IoT fleet. The Device Cloud for Particle Mesh is priced by network. All Particle customers get 10 free micro networks using a Wi-Fi or Ethernet gateway. A micro network is defined as a network with 10 total devices and a single gateway. Please refer to our pricing documentation for more information.


Features:

  • Espressif ESP32-D0WD 2.4G Wi-Fi coprocessor

    - On-board 4MB flash for ESP32

    - 802.11 b/g/n support

    - 802.11 n (2.4 GHz), up to 150 Mbps

  • Nordic Semiconductor nRF52840 SoC

    - ARM Cortex-M4F 32-bit processor @ 64MHz

    - 1MB flash, 256KB RAM

    - IEEE 802.15.4-2006: 250 Kbps

    - Bluetooth 5: 2 Mbps, 1 Mbps, 500 Kbps, 125 Kbps

    - Supports DSP instructions, HW accelerated Floating Point Unit (FPU) calculations

    - ARM TrustZone CryptoCell-310 Cryptographic and security module

    - Up to +8 dBm TX power (down to -20 dBm in 4 dB steps)

    - NFC-A tag

  • On-board additional 2MB SPI flash

  • 20 mixed signal GPIO (6 x Analog, 8 x PWM), UART, I2C, SPI

  • Micro USB 2.0 full speed (12 Mbps)

  • Integrated Li-Po charging and battery connector

  • JTAG (SWD) Connector

  • RGB status LED

  • Reset and Mode buttons

  • On-board 2.4GHz PCB antenna for Thread/BLE (does not support Wi-Fi)

  • Two U.FL connectors for external antennas (one for Thread/BLE, another for Wi-Fi)

  • Meets the Feather specification in dimensions and pinout

  • FCC, CE, and IC certified

  • RoHS compliant (lead-free)



Technical details

Dimensions 51mm x23mm x11mm
Weight G.W 18g
Battery Exclude

Part List

Particle Argon IoT Development Board*1 1
2.4GHz flex antenna 1

ECCN/HTS

ECCN 5A991.b
HSCODE 8517709000
USHSCODE 85177000
UPC 841454121688
FCC 1
CE 1

BUILDING PARTICLE MESH WITH OPENTHREAD

While planning Particle Mesh, we did so with the view that current IoT networks connect only a portion of the interesting places and spaces that developers want to reach. From remote pipelines without an existing Wi-Fi infrastructure to subterranean syste

PARTICLE MESH 102: SELECTING A ROLE FOR YOUR DEVICE

In a Particle Mesh network, there are three types of roles a device can take: a gateway, a repeater, or an endpoint. A previous post, Particle Mesh 101, introduces the basic concepts of roles but stops short of suggesting which role a particular device in

HOW TO BUILD A WIRELESS MESH NETWORK

In the past, building beyond a single-point connection required high-cost hardware solutions and software implementations to connect the in-between spaces needed for device to device communication. As IoT platforms have matured, they have started to embra
