      16mm Anti-vandal Metal Push Button - Royal Blue

      16mm Anti-vandal Metal Push Button - Royal Blue

      SKU 311050001
      $3.50
      7 Available
      $3.50/1pcs+
      $3.15/10pcs+
      $2.98/20pcs+
      $2.80/50pcs+

        I accept the restriction

      This development board can be only used for prototyping, it cannot be built into a product for commercial distribution. It cannot be re-sold or used as part of a production environment.

      Maximum Qty: 5

      Description



      Please read through the guide in Shenzhen 2 U before making any purchase in this catalogue.


      This is a refined metal push button with polished stainless surface and silver as contact material. It takes screw terminals as connectors so that it’s easy to be assembled or removed on a project without soldering.


      This button comes with 6 different colors: Glory Gold,Carbon BlackDark GreenCrimson RedChocolate Brown, and Royal Blue.


      Features

      • Shiny polished surface

      • Reusable screw terminals

      • Long life, 200,000+ push and bounce

      Specifications

      • Diameter: 16mm

      • Degree of protection: IP67

      • Type: Momentary

      • Terminal type: screw terminal

      • Maximum voltage: 250V/AC

      • Contact resistance: 5MΩ(maximum)

      • Life: 200,000 cycles+

      • Operating temperature: -25°C - +65°C

      Datasheet

      Technical Details

      Dimensions50mm x 40mm x 16mm
      WeightG.W 9g
      BatteryExclude

      Part List

      16mm Anti-vandal Metal Push Button - Royal Blue1
