96Boards UART

96Boards UART

SKU 114990282
14.99
47 Available
$14.99/ 1pcs+
$14.24/ 10pcs+

Description

This adapter is a USB to UART interface to be used with any base board compatible with the 96Boards Consumer Edition or Enterprise Edition specifications.

It makes it easy to connect your PC to the serial console on the 96Boards low-speed expansion connector, without worrying about pinout or level shifting for 1.8V IO. It also provides remote control of the power button and reset signals so that the base board can be completely controlled over a single USB cable.

Since it uses the FT230X chip from FTDI, when it is connected to your PC over USB, it appears as a normal UART interface on a PC, Macintosh or Linux computer with an FTDI UART driver installed


Features

  • Attaches to 96Boards low-speed (LS) expansion connector

  • FT230X USB to UART adapter chip

  • USB bus powered. Doesn‘t disconnect when base board power is cycled

  • Switchable between LS UART0 and UART1. (UART1 is the default console)

  • CTS/RTS with using UART0

  • TX and RX LEDs

  • Remote control of baseboard reset and power signals

  • Base board reset button

  • TX and RX LEDs

  • User LED connected to GPIOB (GPIOA on v1.0 of the adapter)


Tech support

This product is desiged by 96 boards, For any technical support or suggestion, please kindly go to their forum .

Technical Details

Dimensions80mm x 120mm x 19.60mm
WeightG.W 6g
BatteryExclude

Part List

96Boards UART (part # 96B-05UART-V1.1)1
2mm shunts2

ECCN/HTS

ECCNNot Available
HSCODE8543709990

Reviews

Questions and Answers

SUBMIT
0
After connecting it to the Hikey960 using LS extended interface then can I connect mouse/keyboard to the USB over it?
on Aug 27,2018
Reply upvote ()
Hi there, please refer to the user guide. https://github.com/96boards/96boards-uart/raw/master/96boards-uart-userguide.pdf thanks.
on Aug 28,2018 14:44 PM
Reply upvote ()
Reply
0
We ar located in northern Germany and looking for a distributor. Would like to have a quotation for 8 pcs.
on Sep 19,2017
Reply upvote ()
Sorry , we haven't information for Germsny Distributor , you maybe check in this link https://www.seeedstudio.com/distributors.html we can support delivery to Germsny.
on Nov 27,2017 18:24 PM
Reply upvote ()
Reply
