This is a dual BTL class-D audio amplifier with single power supply, able to deliver up to 2x40w into 8 ohm speakers, thanks to the high efficiency and exposed-pad-up package only a simple heatsink is required . It can be designed for multimedia player, desktop amplifier, multi channel amp, frequency electronic subwoofer amp etc.
Features:
-
Audio output (L/R)
-
Audio input interface (L/R)
-
Power interface
Specification:
-
SNR 90(db)
-
DR 0.01%
-
Input impedance@ Voltage 4Ω@12V-18V, 6Ω@12V-24V,8Ω@12V-26V
-
size 72mm*60mm*32mm
-
50 W + 50 W continuous output power at THD = 10% with RL = 6 Ω and VCC = 25 V
-
40 W + 40 W continuous output power at
-
THD = 10% with RL = 8 Ω and VCC = 25 V
-
Wide-range single-supply operation (8 - 26 V)
-
High efficiency (η = 90%)
-
Four selectable, fixed gain settings of nominally 21.6dB, 27.6dB, 31.1 dB and 33.6dB
-
Differential inputs minimize common-mode noise
-
Standby and mute features
-
Short-circuit protection
-
Thermal overload protection
-
Externally synchronizable
-
ECOPACK®, environmentally-friendly package
