Particle Boron IoT Development Board (Cellular+Mesh+Bluetooth)

SKU
113990598

Particle Boron IoT Development Board (Cellular+Mesh+Bluetooth),mesh networking,end to end,a standalone cellular endpoint or LTE enabled gateway,u-blox SARA R410 LTE modem,LTE CAT M1/ NB1 module,Particle Device Cloud,Thread,Bluetooth 5,BLE

$49.00
In stock
  • 50+: $48.00
-
+

Pls kindly noted that the first 10pcs shipped out will be Kits which including:

  • Boron LTE dev board
  • Mini breadboard
  • Cellular flex antenna
  • USB cable
  • Starter project includes two resistors (220 ohm), one red LED, and one photodiode

Note: Particle’s MVNO will provide support for LTE M1 connectivity in the US upon initial release. Not in the region? Check out the Boron 2G/3G Kit. See the cellular FAQ for details.

The Boron LTE is a powerful LTE CAT-M1/NB1 enabled development board that can act as either a standalone cellular endpoint or LTE enabled gateway for Particle Mesh networks. It is based on the Nordic nRF52840 and has built-in battery charging circuitry so it’s easy to connect a Li-Po and deploy your local network in minutes.

The Boron is great for connecting existing projects to the Particle Device Cloud or as a gateway to connect an entire group of local endpoints where Wi-Fi is missing or unreliable.

All Particle hardware is designed from the ground up to work with the Device Cloud; a powerful set of tools and infrastructure to build, connect, and manage your IoT fleet. The Device Cloud for Particle Mesh is priced by network. All Particle customers get 3 free months of Device Cloud access for micro networks using a cellular gateway. A micro network is defined as a network with 10 total devices and a single gateway. Please refer to our pricing documentation for more information.

Features:

  • u-blox SARA R410 LTE modem

    - LTE CAT M1/ NB1 module with global hardware support (MVNO support for US only)

    - 3GPP Release 13 LTE Cat M1

  • Nordic Semiconductor nRF52840 SoC

    - ARM Cortex-M4F 32-bit processor @ 64MHz

    - 1MB flash, 256KB RAM

    - IEEE 802.15.4-2006: 250 Kbps

    - Bluetooth 5: 2 Mbps, 1 Mbps, 500 Kbps, 125 Kbps

    - Supports DSP instructions, HW accelerated Floating Point Unit (FPU) calculations

    - ARM TrustZone CryptoCell-310 Cryptographic and security module

    - Up to +8 dBm TX power (down to -20 dBm in 4 dB steps)

    - NFC-A tag

  • On-board additional 2MB SPI flash

  • 20 mixed signal GPIO (6 x Analog, 8 x PWM), UART, I2C, SPI

  • Micro USB 2.0 full speed (12 Mbps)

  • Integrated Li-Po charging and battery connector

  • JTAG (SWD) Connector

  • RGB status LED

  • Reset and Mode buttons

  • Dual SIM support: Nano 4FF (unpopulated) and MFF2

  • U.FL connector for external antenna

  • Meets the Feather specification in dimensions and pinout

  • FCC and PTCRB certified

  • RoHS compliant (lead-free)





Technical details

Dimensions 51mm x23mm x11mm
Weight G.W 18g
Battery Exclude

Part List

Boron LTE dev board 1
Cellular flex antenna 1

ECCN/HTS

ECCN 5A002.a.1
HSCODE 8517709000
USHSCODE 85177000
UPC 841454121695
FCC 1
CE 1
