Description

With LoRa, Wifi and BLE, the LoPy is the only triple bearer MicroPython enabled micro controller on the market today – the perfect enterprise grade IoT platform for your connected Things. With the latest Espressif chipset the LoPy offers a perfect combination of power, friendliness and flexibility. Create and connect your things everywhere, and FAST.


Features


  • Powerful CPU, BLE and state of the art WiFi radio. 1KM Wifi Range

  • Can also double up as a Nano LoRa gateway

  • MicroPython enabled, the Linux of IoT for fast deployment

  • Fits in a standard breadboard (with headers)

  • Ultra-low power usage: a fraction compared to other connected micro controllers


Specification


Processing

  • Espressif ESP32 chipset

  • Dual processor + WiFi radio System on Chip.

  • Network processor handles the WiFi connectivity and the IPv6 stack.

  • Main processor is entirely free to run the user application.

  • An extra ULP-coprocessor that can monitor GPIOs, the ADC channels and control most of the internal peripherals during deep-sleep mode while only consuming 25uA.


Operating Frequencies

  • 868 MHz (Europe) at +14dBm maximum

  • 915 MHz (North and South America, Australia and New Zealand) at +20dBm maximum


Range Specification

  • Node range: Up to 40km

  • Nano-Gateway: Up to 22km

  • Nano-Gateway Capacity: Up to 100 nodes


Interfaces

  • 2 x UART, 2 x SPI, I2C, I2S, micro SD card

  • Analog channels: 8x12 it ADCs

  • Timers: 4x16 bit with PWM and input capture

  • DMA on all peripherals

  • GPIO: Up to 24


Security and Certifications

  • SSL/TLS support

  • WPA Enterprise security

  • FCC – 2AJMTWIPY2R

  • CE 0700


Memory

  • RAM: 512KB

  • External flash 4MB

  • Hardware floating point acceleration

  • Python multi-threading


Hash / encryption

  • SHA, MD5, DES, AES


Wifi

  • 802.11b/g/n 16 mbps


Bluetooth

  • Low energy and classic


RTC

  • Running at 32KHz


Power

  • Input: 3.3V – 5.5V

  • 3v3 output capable of sourcing up to 400mA

  • Wi-Fi: 12mA in active mode, 5uA standby

  • Lora: 15mA in active mode, 1-0uA in standby


LoRa Specification

  • Semtech LoRa transceiver SX1272

  • LoRaWAN stack

  • Class A and C devices


Mechanical


You may need Expansion board or Antenna Kit for your projects.



Certification

HSCODE8473309000
USHSCODE8473309100
UPC841454120513
COOCHINA

Technical Details

Technical details

Dimensions98mm x68mm x21mm
WeightG.W 31.5g
BatteryExclude

Part List

Part List

LoPy 1.0 1

Pycom LoPy MicroPython enabled development board (LoRa, WiFi, Bluetooth)

SKU 109110001
With LoRa, Wifi and BLE, the LoPy is the only triple bearer MicroPython enabled micro controller on the market today – the perfect enterprise grade IoT platform for your connected Things.
USD$28.90
Discontinued
