Grove - Screw Terminal
  • Grove - Screw Terminal
  • Grove - Screw Terminal

Grove - Screw Terminal

SKU 103020007
  • Grove compatible interface
  • 3.5mm pitch pin
  • Accept 30 to 20AWG wire
    $2.90
    45 Available
    Qty:
    This field is required
    ADD TO CART
    $2.90/1pcs+
    $2.61/10pcs+
    $2.47/20pcs+
    $2.32/50pcs+
    Description

    Grove - Screw Terminal with four 3.5mm pitch pins rated up to 6A. Terminal can accept 30 to 20AWG wire. It is most commonly used pitch screw terminal. This Grove has four ports including GND, VCC and two other ports. This Grove can be used to interface Grove wires(signals) with other external non-Grove modules. This Grove acts as a wiring form factor converter.


    Features

    • Grove compatible interface

    • 3.5mm pitch pin

    • Accept 30 to 20AWG wire


    Specification

    • Operating voltage: 3.3~5V


    Documents

    Please visit our wikipage for more information about this product. For technical support, please post your questions on our forum.

    For all Grove users (especially beginners), we provide you guidance PDF documents. Please download and read through Preface - Getting Started and Introduction to Grove before your using of the product.

    See More
    $50 Featured List
    $100 Featured List
    $200 Featured List
    Don’t miss out!
    Questions and Answers
    SUBMIT
    0

    please help I dont know if i understood. if i want to drive a 3 V DC motor I only have to attach a 3 V DC Powersource?
    and could i regulate the motor with the output voltage?

    on Oct 19,2016
    Replyupvote ()

    Hi,
    I can help with this.
    It is specified copper thickness _1.18mil. That should be around 1.0oz copper. based on that you need 150mil track width for 10 amp, assuming a 30degC rise. Keep your track as short as possible. If you need more current

    on Oct 20,2016 10:43 AM
    Replyupvote ()

    This product is just as a expanding board, the voltage of Vcc and signals depend on your main board (micro controller). If you use Seeeduino/Arduino, the voltage of them are 5v. Could it be clear ?

    on Oct 20,2016 10:48 AM
    Replyupvote ()
    Reply
    0

    how do you connect the moters?

    on Oct 19,2016
    Replyupvote ()

    Hey Shakeel, it depends on what kind of motor you will use. Basically the Vcc pin and GND pin are used for the power supply. The D1 pin and D2 pin are used for controlling your motor.

    on Oct 20,2016 10:47 AM
    Replyupvote ()
    Reply
