Grove - Temperature Sensor uses a thermistor to measure ambient temperature. The resistance of thermistor changes based on ambient temperature. This resistance value alters the output of a voltage divider which is measured by an analog input pin and converted to a temperature value. The operating range is -40 to 125°C , with an accuracy of 1.5°C .
For all Grove users (especially beginners), we provide you guidance PDF documents. Please download and read through Preface - Getting Started and Introduction to Grove before your using of the product.
|Dimensions||24mm x20mm x9.8mm|
|Thermistor Zero power resistance||100 KΩ|
|Nominal B-Constant||4250 ~ 4299K|
|Operating temperature range||-40°C to 125°C|
|Grove - Temperature Sensor||1|
The Environment Cube! Know the Land Beneath You using Sigfox
A cube with all the necessary sensors, suitable for a wide range of applications like agriculture, monitoring, ,etc.
BBGW starter tutorial#4:How hot is it today? Ask BBGW!
It is so hot today! And I need to know that what the temperature in my office now. What’s more, sunshine seems too strong also want get light intensity. Now decide make a display of these two things with BBGW and show it boss! Ask for an ice cola ...
Home Control Center using BeagleBone Green Wireless
SeeedStudio BeagleBone Green Wireless(SeeedStudio BBG Wireless) is a joint effort by BeagleBoard.org and Seeed Studio. The Wireless has included two Grove connectors support mraa library, making it easier to connect the ...
Baby Monitor with Wifi Micro
Now a days there are many wearables in market for different purposes, so why not we make one babies. With increase nuclear families is no to guide the new parents about their born baby. They always worried baby regarding his health, ...
Terrarium and Linkit ONE
features: -control the water in tank (if to low switch all tools off) -control humidity over 70% foger off ) -control light (switch on at 6h00 and 23h00) -control Temp under 30°C heaters if 35°C Heater temp 45°C on) -control rain ...
An IoT demo made with Arch Link(Mbed Platform)
An IoT demo made with Arch Link(Mbed Platform)
Lección 11 : Módulo Grove sensor de temperatura.
En esta lección vamos a aprender a conectar y programar el módulo GROVE sensor de .Thanks Javier Martinez provide this lesson for introduction to Seeeduino with Grove Starter Kit.
Lesson 11 : Temperature sensor Grove module.
In this lesson you will learn how to connect and program the temperature sensor grove module.Thanks Javier Martinez provide this lesson for introduction to Seeeduino with Grove Starter Kit.
Grove - Temperature Sensor
The Grove - Temperature Sensor uses a Thermistor to detect the ambient temperature. The resistance of a thermistor will increase when the ambient temperature decreases. It's this characteristic that we use to calculate the ambient temperature. The detecta
Hi Terry, I only need to know the properties and origin of this function to adapt it to my ADC settings (12 bits and 3,3V as VCC). I think that this sensor is generic sensor and it can be used with different platforms and ADC configurations. For this,Question by: admin on 2018-12-18 02:39:07
The Vref value of seeeduino is 5V and Seeeduino is a 10 bit ADC. If you select other microcontroller, you can set ADC. There is a Grove - I2C ADC using to get more precise value, you can have a try.Answer by: admin on 2018-12-18 02:39:07
How would be this function if I use an 12 bits ADC and 3,3 Vcc: float readTemp()
const int B=3975;
int sensorValue = analogRead( tempPin );
TQuestion by: admin on 2018-12-18 02:39:07
I only need to know the properties and origin of this function to adapt it to my ADC settings (12 bits and 3,3V as VCC). I think that this sensor is generic sensor and it can be used with different platforms and ADC configurations. For thiAnswer by: admin on 2018-12-18 02:39:07
We took your code from the project seven website wiki into the arduino and I'm not able, to reach over lets say an outputabove 45 to 50?°C.
Have you ever made a test above the 50?°C?
Temps around -20 to 30?°C are very good, but when going higQuestion by: admin on 2018-12-18 02:39:07
I changed the NTC meanwhile and checked the NTC that was on the boards, they seem to be 5K not 10K, not very shure. Now I use 10 K NTC without the LM, but this works good now.Answer by: admin on 2018-12-18 02:39:07
Can you confirm the part number of the thermistor please (or the B value)?
The graph in the data sheet is for the TTC3A103#34D, but the B value in the sample is for the TTC3A103#39H.Question by: admin on 2018-12-18 02:39:07
TTC3A103#39H.Answer by: admin on 2018-12-18 02:39:07
The schematic for this module does not appear to be correct. Is the IC a current source in series with the thermistor?Question by: admin on 2018-12-18 02:39:07
The new version of Stalker will come here a month later.Thanks for your attention.Answer by: admin on 2018-12-18 02:39:07
I'm looking for the temperature equation for the v1.1 of this. I get that the B value has changed from the sample but the equation on the SeeedStudio github produces clearly absurd results (raw value comes in at around 520-530 for room temperature).<Question by: admin on 2018-12-18 02:39:06
Sorry for the delayed reply.We have updated the wiki for V1.1/V1.2 and the new equation provides correct value.Answer by: admin on 2018-12-18 02:39:06
Can you please confirm which thermistors are used on board revisions v1.0, v1.1 and v1.2?
I am trying to find accurate B values.Question by: admin on 2018-12-18 02:39:06
Check the new wiki for updated equation for V1.2/V1.1 http://www.seeedstudio.com/wik...Answer by: admin on 2018-12-18 02:39:06
I have purchased this recently and trying to follow example at http://learn.adafruit.com/tmp3...
However I do not find the resolution in millivolt/deQuestion by: admin on 2018-12-18 02:39:06
Can you please let me know in which document equation used at wiki:http://www.seeedstudio.com/wik... is documented. In datAnswer by: admin on 2018-12-18 02:39:06
I need sensor which will be able to measure temperature 80-90-100C. Does your sensor able to measure this temperature ?Question by: admin on 2018-12-18 02:39:06
yes,you can.But please pay attention to the working time,this is not a industrial product,so you may not use it in a very hard situation too long.Answer by: admin on 2018-12-18 02:39:07
sensor gives wrong readings...temp changes constantly and every third read temp drops from average of 22 celsius to 7 celsius...why is that??Question by: admin on 2018-12-18 02:32:04
Hi~We tested our sensor with the demo from our wiki,and it works well.So could you please tell us about the code you use and send a picture and log to our support email. email@example.com ~~~ThanksAnswer by: admin on 2018-12-18 02:32:05
Hello.. I am trying to use this sensor with Intel Edison and write python code. I received it as part of relayr IoT starter kit. Which software python library should I use to access this sensor's reading? I have libmraa 1.4 installed, but it does not have pyupm_temperature module. I tried using otp538u module, but it prints an error saying 'ambient temperature out of range'. Could you please respond to this query.Question by: admin on 2018-12-18 02:23:28
Please refer the Intel Edison python code of Grove Temperature Sensor from the following link: https://software.intel.com/en-us/iot/hardware/sensors/grove-temperature-sensor.Answer by: admin on 2018-12-18 02:23:28
When using the temperature sensor with the Grove IoT Commercial Developer Kit, room temperature Celcius is 50. Farenheit is 120. The raw value is 757 (varies). These are obviously incorrect. I have the temp sensor plugged into A1 and am using Node-Red. I thought it would be seamless using the Intel NUC. What am I missing?Question by: admin on 2018-12-18 02:23:18
I'm using the Grove Shield that came with the Dev kit set to the 5V side.
There is no code. I'm using the IoT Developer Hub, Node-Red definition with the following settings:
Yielding a result of:Answer by: admin on 2018-12-18 02:23:18
CAn you give me the link for the I2C pin type sensor?? Because the link you provided below is the same as this page.Question by: admin on 2018-12-18 02:21:35
Hello,what do you mean I2C pin type sensor?Answer by: admin on 2018-12-18 02:21:35
Hi .. I am unable to read from the grove temperature via an I2C pin on arduino board. Are there any specifications that illustrate the process or at least the addresses that I should interface with?Question by: admin on 2018-12-18 02:20:24
Hi, this is not an I2C type sensor .Answer by: admin on 2018-12-18 02:20:24
