      Grove - Chainable RGB LED

      Grove - Chainable RGB LED

      SKU 104030006
      $3.90
      OUT OF STOCK
      This item is not available at the moment
      Get notified when it's back in stock

      Description

      Note: This product will EOL soon, please click here for Grove - Chainable RGB LED V2.0.


      The Grove Chainable RGB LED is based on P9813 chip which is a full-color light source LED driver chip,can provide constant current drive and modulated output of 256 gray.Transmission by wire (DATA and CLK), built-in recycling, can enhance the transmission distance.


      For all Grove users (especially beginners), we provide you guidance PDF documents. Please download and read through Preface - Getting Started and Introduction to Grove before your using of the product.



      Documents

      Please visit our wiki for more info about this product. It will be appreciated if  you can help us improve the documents, add more demo code or tutorials. For technical support, please post your questions to our forum.

      Technical Details

      Dimensions24mm x 20mm x 25mm
      WeightG.W 7g
      BatteryExclude
      Operating Voltage5V
      Operating Current20mA
      Communication ProtocolSerial

      Part List

      Grove - Chainable RGB LED1

      Reviews

      Questions and Answers

      SUBMIT
      0

      It would be good if you please, specify in the"Description", that it DOES include a grove cable.
      I thought It didn't included one, so I bought lots of cables. And when my package arrived, I noticed that It already had the needed cable included.

      on Oct 19,2016
      Replyupvote ()
      <p>Thank you for your suggestion. we will add this in the description.</p>
      on Oct 20,2016 10:48 AM
      Replyupvote ()
      Reply
      0

      The LED light is always on when plugged in. How can I set it off all the time unless I turn if on?

      on Oct 19,2016
      Replyupvote ()
      <p>It is a problem of your program, please modify it. And it does not have a default status.</p>
      on Oct 20,2016 10:48 AM
      Replyupvote ()
      Reply
      0

      The P9813 datasheet lists a company I cannot yet find. The datasheet indicates that the P9813 chip will drive qty 3 sets of RGB LED strings ( for a total of 9 strings ). Each string can be multiple LEDs. I cannot yet tell how much current each string c

      on Oct 19,2016
      Replyupvote ()
      <p>Sorry for replying lately, Joanne. This grove module only ships with one RGB LED. Maybe the designer of it think it's neat for demonstration. According to its datasheet <a href="http://www.seeedstudio.com/wiki/images/b/be/P9813_datasheet.pdf" rel="nofo
      on Oct 20,2016 10:47 AM
      Replyupvote ()
      Reply
      0

      How bright is the LED on this board? Are there boards with multiple LEDs/driver chips pre-chained? e.g. a unit with 10 already chained up would be great.

      on Oct 19,2016
      Replyupvote ()
      <p>Hi,the power of each LED is about 0.1w.And it has 9 driver chips worked if you combined 10 LEDs together.</p>
      on Oct 20,2016 10:42 AM
      Replyupvote ()
      Reply
      0

      How many of these can I chain to an arduino uno? Are the LEDs individually adressable?
      Hamish

      on Oct 19,2016
      Replyupvote ()
      <p>Hi Hamish , the Maximum number LED is 1024 ,they doesn't have a individual adressable , but can be controlled individually.</p>
      on Oct 20,2016 10:42 AM
      Replyupvote ()
      Reply
